55cm Large Type Double-Arm Tea Roller Machine With Stainless Steel Table DL-6CRT-55

DL-6CRT-55 can process almost all kind tea, the part contacted with tea is made of stainless steel, drum diameter 55cm, height 40cm, capacity about 35 kg per batch.

  • Model : DL-6CRT-55
  • Dimension : 1580*1400*1390 mm
  • Input voltage : 380V / 50Hz
  • Tea disc diameter : 1050 mm
  • Barrel diameter : 550 mm
  • Barrel height : 400 mm
  • Max capacity per batch : 35 kg/batch
  • Capacity for green tea : 35-350 kg/h
  • Capacity for black tea : 35-70 kg/h
  • Maklumat produk
   DESCRIPTION

For fermented tea such as black tea and dark tea: Through the external force of the tea rolling machine, the tea leaf\'s juice overflows, the tea cells are damaged, accelerates the enzymatic oxidation of polyphenolic compounds, provided conditions for subsequent fermentation of tea leaves, Improve the taste of finished tea and make the quality of tea better.

For non-fermented tea such as green tea and oolong tea: The main function of DL-6CRT-55 tea rolling table is shaping the tea leaves, through the extrusion of the tea rolling machine, the tea leaves are rolled and compressed, and the fresh leaves are twisted into strip shape.

   ADVANTAGE

1. The disc, the tooth bar, the barrel and the lid are made of stainless steel;
2. The double arms adopt a double-arm open cover structure, which has a strong bearing capacity and stable operation.
3. The arc of the rolling bar has been improved for decades, and the optimal design has been obtained. The efficiency of tea leaves been the strip-type is increased by 30%.

4. The height design of the purlins is formed by a one-time mold, so that the height and angle of the strips are uniform, so that the tea strips are more compact and beautiful.

   EXPLODED VIEW

55cm Large Type Double-Arm Tea Roller Machine With Stainless Steel Table DL-6CRT-55

Transverse arm Press spring
Barrel cover Support Column
Stainless steel Drum Handwheel
Crank Support frame
Transmission case Rolling disc
Transmission belt Tea outlet
Drive motor Support leg



   APPLICATION

Double Action Tea Roller is suitable for processing black / green / oolong / white / dark / herbal tea, the following is the working time required for the above tea production.

 Type Of Tea  Working Time
 Black Tea  30-90 minutes
 Green Tea  4-6 minutes
 Oolong Tea  4-6 minutes
 Herbal Tea  4-6 minutes

The above data is for reference only, and the specific processing time shall be determined according to the actual situation.

   SPECIFICATION

Double Action Tea Roller specification list:

Model DL-6CRT-55
Dimension 1580*1400*1390 mm
Input voltage 380V / 50Hz
Tea disc diameter 1050 mm
Barrel diameter 550 mm
Barrel height 400 mm
Matching motor Power 2.2 kW
Speed 1400 RPM
Rated voltage 380 V
Barrel speed 45 RPM
Weight 420 Kg
Max capacity per batch 35 kg/batch
Capacity for green tea 35-350 kg/h
Capacity for black tea 35-70 kg/h

Specification of all of Double Action Tea Roller.

Model Barrel Diameter Barrel Height Capacity
6CRT-25 25 cm 18 cm 3 kg/batch
6CRT-30 30 cm 21 cm 5 kg/batch
6CRT-35 35 cm 26 cm 8 kg/batch
6CRT-40 40 cm 25 cm 11 kg/batch
6CRT-45 45 cm 28 cm 15 kg/batch
6CRT-50 50 cm 28 cm 20 kg/batch
6CRT-55 55 cm 40 cm 35 kg/batch
6CRT-65 65 cm 48 cm 60 kg/batch

If you have special need, it can be customized according to the needs of customers.

   DETAILS

Tea Roller Processing

55 Type tea rolling machine, the diameter of rolling barrel is 55cm, height 40cm, can put about 35-40 kg tea in it, for green tea 1 hour can roll 35-350kg, for black tea 1 hour can roll 35-80 kg.



Tea Roller Machinery

Enlarged handwheel design, faster lifting of the barrel cover.



Orthodox Tea Roller Machine

The double arms adopt a double-arm open cover structure, which has a strong bearing capacity and stable operation.



Tea Roller Equipment Manufacturing

Turbine worm gearbox design, deceleration is stable and durable.

   PHOTOS

Tea Roller Equipment Machine

Tea Roller Double Action

Orthodox Tea Roller Double Action Processing Machine Equipment

Orthodox Tea Roller Double Action Processing Machine Equipment
